The Uberbike SRAM GXP compatible bottom brackets have been specifically designed for use with either 68mm or 73mm BSA threaded MTB or Road bottom bracket frame types using a GXP / Truvativ 24mm (drive side) and 22mm (non-drive side) spindle diameter chainsets.

The bottom bracket cups are CNC machined from lightweight but strong 6061 alloy and are available in a range of 8 anodised finish options. For bearings, we have selected to use carbon steel over standard chrome steel bearings for their superior hardness and increased load capacity, offering a higher life cycle which makes them an ideal choice for mountain and road bike bottom brackets, with the 2 rubber seals acting as a barrier to help lock out dirt and ingress, whilst keeping the lubrication trapped inside.

Features

• Compatibility - Frame type 68/73mm BSA threaded / GXP / Truvativ 24mm spindle (drive side) and 22mm spindle (non-drive side)  diameter chainset
• Lightweight CNC machined 6061 alloy cups with replaceable bearings, anodised finish with laser engraved logo.

• Composite centre tube double O-ring sealed, external custom-lipped outer seals.

• Carbon Steel sealed bearings offer increased durability and a higher life cycle than standard bearing types.

• Weight - 103g.
• Requires 16-point 44mm OD installation tool.

• For installation, always use a qualified technician.
